The SlamSet is made for riders who can't get the front of the bike low enough without compromising on bearing and seal quality. Equipped with Hellbender stainless steel bearings, the SlamSet is characterised by durability and longevity and offers the best steering performance.
Use:
Designed for 1 1/8" upper head tube diameters and 1.5" lower head tube diameters combined with 1 1/8" - 1.5" tapered forks.
Specifications:
Upper Cup: 1 1/8"
Lower Cup: 1.5"
Steerer Tube: 1 1/8" - 1.5"
Design: Zero Stack (ZS)
Technical Information:
Material: aluminium (7075)
Bearings: Hellbender stainless steel, sealed
Upper Stack Height: 2 mm
Lower Stack Height: 4 mm
Upper Outer Diameter: 44 mm
Upper Inner Diameter: 28.6 mm
Lower Outer Diameter: 56 mm
Lower Inner Diameter: 40 mm
Features:
- very low axle to crown enables a particularly flat cockpit
- sealed Hellbender stainless steel bearings for best durability and long service life
Standardized Headset Identification System (S.H.I.S.):
In order to clarify and bring uniformity to a sea of headset standards, manufacturers Acros, Cane Creek, Hope, Race Face, Reset Racing and Ritchey have agreed upon using a shared nomenclature, which will likely include more participating companies in the future. This system takes into account a combination of frame and fork dimensions. Both the upper and lower part of the headset are marked by two alphanumeric identifiers. The first identifier indicates the type of headset (External Cup, Zero Stack, Integrated) and head tube diameter. The second identifier - separated from the first by a backslash - indicates the diameter of the steerer tube. When referring to a complete headset, the specifications of both upper and lower parts must be combined.
Nomenclature:
EC: Bearings contained within cups that are located outside of the frame (external cup).
ZS: Bearings contained within pressed-in cups where the cup and bearings rest inside the frame (zero stack).
IS: Bearings that fit directly into a bonded or machined interface that is integrated into the frame (integrated).
Contents:
- 1 x Cane Creek upper headset cup incl. stainless steel bearings
- 1 x Cane Creek lower headset cup, incl. stainless steel bearings
- 1 x Cane Creek headset cap
- 1 x Cane Creek top cap assembly
- 1 x Cane Creek crown race
- incl. star nut & bolt
