Trail 7 27.5" Bikes

Details

With its progressive geometry, impressive construction and high-end features, the Trail offers unreal performance and a killer value. It's designed for short stems and wide handlebars to maximize control in rough terrain, while the slack 68° head angle creates the stable, confident handling you need to rule the descents. Short chainstays give the Trail an agile, nimble feel and provide great traction on steep climbs. With Shimano hydraulic brakes, a reliable 2x drivetrain, and great tires, the Trail 7 is ready to rock.

Specs

Frame : Trail, SmartForm C2 Alloy, SAVE, 1-1/8” head tube

Fork : SR Suntour XCM, 100mm, Coil, 51mm offset

Headset : Sealed Semi Integrated, 1-1/8 reducer

Axles

Front: QR

Rear: Boost QR

Rims/Wheels : WTB SX19, 32h

Hubs : Formula w/ HG driver

Spokes : Stainless Steel, 14g

Tires : WTB Ranger Comp, 27.5/29 x 2.25" DNA Compound

Crankset : FSA Comet, Alpha Drive

Chainrings : 36/22

Bottom Bracket : Sealed Bearing BSA

Chain : KMC HG53, 9-speed

Front Derailleur : MicroShift Direct Mount

Rear Derailleur : Shimano Altus

Cassette/Rear Cogs : Sunrace, 11-36, 9-speed
Shifters : Shimano Easy Fire EF505, 2x9

Handlebars : Cannondale C4 Riser, 6061 Alloy, 25mm rise, 8° sweep, 6° rise, 720mm

Tape/Grips : Cannondale Dual-Density

Stem : Cannondale C4, 3D Forged 6061 Alloy, 1-1/8", 31.8, 7°

Brake Levers : Shimano MT200 hydro disc

Brakes : Shimano MT200 hydro disc, 160/160mm RT26 rotors

Pedals : Cannondale Platform

Saddle : Cannondale Stage 3

Seat Post : Cannondale C4, 6061 Alloy, 31.6 x 400mm
