Specifications
Compatibility
Rear axle: 12mm thru axle, convertible to Quick Release with optional adapters
Freewheel: Shimano/Sram or XD
Front axle: 20mm, convertible to 15mm thru axle with included adapters
Weight
Pair 650b/27,5" without tyre: 1710 grams
Front 650b/27,5" without tyre: 810 grams
Rear 650b/27,5" without tyre: 900 grams
Hubs
Freewheel: ITS-4 alloy
Front and rear bodies: aluminum
Adjustable sealed cartridge bearings (QRM+)
Intended Use
Recommended tyre sizes: 44 to 76 mm (1.75" to 3.0") front and 50 to 76 mm (2.0" to 3.0") rear
For a longer longevity of the wheel, Mavic recommends that the total weight supported by the wheels don't exceed 120kg, bike included
ASTM CATEGORY 4 : ENDURO AND TRAIL RIDING
Rims
Hookless profile
Internal width: 28 mm front and 25mm rear
ETRTO size 27.5": 584x28TSS front & 584x25TSS rear
Weight reduction: ISM 4D
Valve hole diameter: 6.5 mm
Tyre: UST Tubeless and tubetype
Drilling: Fore
Material: Maxtal
Spokes
Shape: straight pull, bladed
Lacing: front crossed 2, rear Isopulse
Nipples: Fore integrated aluminum
Count: 24 front and rear
Material: Zicral
Versions
Hub width : Boost (front 110, rear 148) or Non-Boost (front 100, rear 135/142)
Disc standard : 6 Bolts only
Color: Black only
